208–3.4 PLACING. Place aggregate base material on the prepared underlying course and compact in layers of the thickness shown on thePlans. Deposit and spread the material where designated and progress continuously without breaks. Deposit and spread material in lanes in auniform layer and without segregation of size to a loose depth that, when compacted, the layer shall have the required thickness. Spread baseaggregate on a moistened subgrade, in layers of uniform thickness. Dumping from vehicles in piles that require rehandling shall not bepermitted. Hauling over the uncompacted base course is not permitted.
0:38
3:44
I'll look for my imperfections. I'll run string lines to make sure I'm right fill in some of thoseMoreI'll look for my imperfections. I'll run string lines to make sure I'm right fill in some of those low spots. Take down some of those high spots.
What is the meaning of aggregate base course?
underlying course to the required density before the base course is placed thereon. To protect the underlying course and to ensure proper drainage, begin spreading the base along the centerline of the pavement on a crowned section or on the high side of the pavement with a one–way slope. 208–3.3 MIXING. Uniformly blend the aggregate during crushing operations or mix in a plant. …
How much compaction for aggregate basecourse/sub-base?
SECTION 304 DIVISION 300-- BASE COURSES SECTION 304 -- AGGREGATE BASE COURSE Description 1.1 This work shall consist of furnishing and placing base courses on a previously prepared subgrade or course as shown on the plans or as ordered. 1.2 This work shall also include raising the grade of the edge of the roadway shoulders with crushed aggregate as shown
Can I dump aggregate base in piles on subgrade?
When subgrade is cohesionless soil and you decide that the subgrade is unstable for placing aggregate base on the roadbed in layers or windrows, you may give the contractor written permission to dump aggregate base in piles and spread ahead. Determine whether the contractor has complied with all requirements related to the use of local materials.
What percentage of modified Proctor do you use for aggregate base courses?
Jul 12, 2009 · In principle the crushed stone base after the compaction finish the section must be slushed by a pneumatic or tyred roller inorder to bring all fines to surface.All the fines must be broomed prior to primming.This will enable the primer to penetrate into the base for at least (3-10)mm.This will make good bonding between the pavement layers(base course)to receive the …
How do you compact an aggregate base?
0:00
2:47
Spread each lift as close as you can to the correct depth and gray then compact it start around theMoreSpread each lift as close as you can to the correct depth and gray then compact it start around the perimeter. And then work your way toward.
How do you compact paver bases?
The best practice is to compact your gravel base, in both directions, with a steel tamper or a plate compactor 2″ at a time until you've achieved the right thickness. You'll want to use a steel tamper for small projects and a gas plate compactor for more extensive patios, driveways, and walkways.Jun 8, 2020
How do you compact a sub-base without a compactor?
How to Compact Pavers without a Plate Compactor
- Step 1: protective clothing. Ad. ...
- Step 2: prepare the substrate. Check the underground in the pit carefully. ...
- Step 3: create a layer of frost protection. ...
- Step 4: Build the base course. ...
- Step 5: Apply a layer of sand. ...
- Step 6: clean the vibrating plate.
How do you compact a sub-base for a driveway?
How is a sub-base laid for a driveway?
- Spread layers of max. 150mm with rakes. ...
- Compact the layer by multiple passes with equipment until compacted fully. ...
- It must be level checked to make sure even, to a typical tolerance of +10mm to –15mm. ...
- It's important that it's tight, i.e. no pockets or holes.
Jun 28, 2021
Should you wet sub-base before compacting?
You'll want to ensure that the water penetrates the entire depth of the sub-base material from top to bottom, but you'll want to avoid flooding the surface. If the base is too wet, you'll find that your plate compactor sinks too deep into surface. If this is case, allow the aggregate to dry out.Feb 9, 2018
Should you wet type 1 before compacting?
Yes it will be fine, compact it in 50mm layers wetting it before compacting, it will goes as hard as concrete.Mar 2, 2016
What can I use instead of a plate compactor?
An ordinary sledgehammer is a better hand-operated tool for tamping. Handle vertical, lift and drop, repeat. Doing a good job with one is tedious but quite possible if you prefer not to rent a powered plate compactor. For something like compacting around a fencepost, an iron digging bar can be used to compact.Aug 13, 2020
What happens if you dont compact sub-base?
Each time a vehicle pulls into a garage and stops, that action creates a plate compactor effect. If the backfill under the slab has not been properly compacted, the structural fill will eventually settle, leaving voids.
How do you compact ground manually?
0:47
5:29
Going on it so what you want is to make sure that you have a straight surface what works for me is iMoreGoing on it so what you want is to make sure that you have a straight surface what works for me is i actually open my legs about shoulder width i hold the pamper.
Can I use 20mm gravel as a sub-base?
0-20mm ballast is perfect for sub-base and concrete foundations. 20mm screened ballast is versatile and can be used on driveways, footpaths, oversite fill as well as sub-bases.Dec 18, 2019
Can you use broken concrete as sub-base?
It will be fine.Apr 21, 2020
Can I use gravel as sub-base?
If your builder uses the gravel he may find it will dissipate too easily into the ground and will spend more time and money to get the levels needed. I would not advise using the gravel. A well constructed base means your drive will never get sink holes.
4-2601 General
This section provides guidelines for inspecting aggregate bases for work specified under Section 26, “Aggregate Bases,” of the Standard Specifications.
4-2602 Before Work Begins
Before placement begins, review the contract plans and specifications to determine the aggregate base requirements. For sampling and testing requirements, including frequency of testing, refer to Chapter 6, “Sampling and Testing,” of this manual.
4-2603 During the Course of Work
Sample the aggregate base at the time it is deposited on the roadbed. Observe delivered aggregate base to ensure that it is clean of debris and other harmful materials. For requirements related to material quality, perform the tests at the frequencies shown in Section 6-1, “Sample Types and Frequencies,” of this manual.
4-2604 Level of Inspection
Suggested levels of inspection for typical aggregate base work activities are:
4-2605 Quality Control
Guidance for quality control activities included in this section is summarized as follows:
4-2606 Payment
Review the quantity calculations in the resident engineer’s file to determine if they are sufficiently detailed and accurate to be used in the project records.
Why flat base course for concrete?
A flat base course will also allow the slab to slide easily as it shrinks, reducing restraint and the risk of cracks as the concrete contracts after placement (drying shrinkage).
What is a base course?
Base (or base course)—this is the layer of material on top of the subbase and directly under the slab. A compacted subbase keeps workers out of the mud. Energy Efficient Building Network. The only layer that is absolutely required is the subgrade—you have to have ground to place a slab on ground on top of.
What is below a concrete slab?
What lies below your concrete slab is critical to a successful job. This is no different than the foundation for a building. A slab on ground (or slab on grade) by definition is not intended to be self-supporting. The "soil support system" beneath it is there to support the slab.
What is the only layer of soil that is required to make a slab?
The only layer that is absolutely required is the subgrade —you have to have ground to place a slab on ground on top of. If the natural soil is relatively clean and compactable, then you can put a slab right on top of it without any extra layers.
What is subbase material?
The subbase material is usually a reasonably low cost gravel without a lot of fines. Recycled crushed concrete is an excellent source for subbase material. The Concrete Producer. A base course on top of the subbase makes it easier to get to the proper grade and to get it flat.
When excavating a building site, what happens to the soil?
When a building site is excavated, usually the soil gets moved around—high spot s are cut and low spots are filled. Everything then should get compacted before you place the concrete, subbase and base. The type of soil determines what needs to happen before placing a slab.
What is the best solution for slabs on poor soil?
Post tensioning is often the best solution for a slab on poor soil. J.C. Escamilla's Concrete. Most natural soil, of course, is a mixture and so is characterized by the type of material that is predominant.
