A course deviation indicator (CDI) is an avionics instrument used in aircraft navigation to determine an aircraft's lateral position in relation to a track. If the location of the aircraft is to the left of course, the needle deflects to the right, and vice versa. Use The instrument shows the direction to steer to correct for course deviations.

Full Answer

When should the course deviation indicator (CDI) needle be centered?

When the course deviation indicator (CDI) needle is centered during an omnireceiver check using a VOR test signal (VOT), the omnibearing selector (OBS) and the TO/FROM indicator should read A.180° FROM, only if the pilot is due north of the VOT.

What is the standard deviation indicator?

The standard deviation indicator can useful to filter trading signals according to trending or ranging markets. Usually, the lower the standard deviation value, the less volatile the market is. An increase in the value of the standard deviation can identify an increase in market activity.

How do you determine the course deviation of an aircraft?

If the course selector is rotated until the deviation needle is centred, the radial (magnetic course “FROM” the station) or its reciprocal (magnetic course “TO” the station) can be determined. The course deviation needle also moves to the right or left if the aircraft is flown or drifting away from the radial which is set in the course selector.

Where should the course deviation bar be on the instrument?

As you can see in the CDI, if the aircraft follows the desired radial heading, the radial direction is represented by the location of the course deviation bar on the instrument. If now the aircraft is exactly on the radial, the course deviation bar should be centered on the instrument.

What is an HSI in aviation?

The horizontal situation indicator (HSI) is a key instrument in IFR flight. It combines the functions of a heading indicator and navigational indicator into a single instrument. For HSI questions, first determine the aircraft heading shown at the top of the indicator.

What is CDI and OBS?

OBS vs CDI The OBS (Omni-Bearing Selector) is the knob that the pilot adjusts. On the other hand, the CDI (Course Deviation Indicator) is the needle in the window that shows your desired course. So the pilot turns and sets the OBS but sees their course by looking at the CDI needle.

What is the difference between a CDI and HSI?

A standalone CDI (Course Deviation Indicator) is an instrument that shows your deviation from a VOR radial that is selected using the OBS (Omnibearing Selector) knob located on the instrument itself. An HSI (Horizontal Situation Indicator) is an entirely separate instrument that combines a CDI and a heading indicator.

How does an RMI work?

RMI treats a remote object differently from a non-remote object when the object is passed from one Java virtual machine to another Java virtual machine. Rather than making a copy of the implementation object in the receiving Java virtual machine, RMI passes a remote stub for a remote object.

How do you read a CDI indicator?

On the CDI instrument just read the number displayed on the compass card (±90° of the radial). In the left figure above, the shortest path to join the VOR radial is 340° (=070°-090°) (blue straight arrow). The VOR is located in the sector between 340° and 070° as we are in the TO region.

How do I read OBS indicators?

2:158:28Simple Way to Determine Aircraft Position Using a VOR, CDI, and OBSYouTubeStart of suggested clipEnd of suggested clipSo the shaded red area is the area that we cannot be in if the Idul is deflected to the right andMoreSo the shaded red area is the area that we cannot be in if the Idul is deflected to the right and our OBS is set to three six zero.

What is the purpose of the course deviation bar in the HSI?

The HSI has a fixed aircraft symbol and the course deviation bar displays the aircraft's position relative to the selected course. The TO/FROM indicator is a triangular pointer: When the indicator points to the head of the course select pointer, the arrow shows the course selected.

Can an HSI reverse sense?

The HSI combines a heading indicator with CDI needles. As long as you tune the front course for the localizer, you won't get reverse sensing.

How many degrees are each dot on an HSI?

Each division (dot) represents 1.25 degrees deviation from the ideal ILS flightpath approach.

What is the difference between RMI and ADF?

The RMI differs from the movable-card ADF in that it automatically rotates the azimuth card (remotely controlled by a gyrocompass) to represent aircraft heading. The RMI has two needles, which can be used to indicate navigation information from either the ADF or the VOR receiver.

What is relative bearing indicator?

relative-bearing indicator (RBI) An indicator in which the compass card is fixed with 000° at the top of the display, and the pointer indicates bearing to the beacon relative to the aircraft heading. This can be a radio bearing or an omnibearing.

What is ADF in aviation?

The Automatic Direction Finder (ADF) is an aircraft navigation product that automatically calculates the relative bearing of the aircraft to the radio station.

What is radial indicator on CDI?

In the CDI instrument, the radial indicator is a needle which is clearly visible on the top of the instrument. If the location of the aircraft is to the left off course, the needle deflects to the right. If the location of the aircraft is to the right off course, the needle deflects to the left. If the location of the aircraft is on ...

What happens when the course selector is rotated?

If the course selector is rotated until the deviation needle is centred, the radial (magnetic course “FROM” the station) or its reciprocal (magnetic course “TO” the station) can be determined. The course deviation needle also moves to the right or left if the aircraft is flown or drifting away from the radial which is set in the course selector.

What is CDI display?

CDI display is independent from the aircraft heading. Note that in the CDI instrument, the display is independent from the aircraft heading. This can be strange for novice pilots to instrument navigation. The instrument displays the information in the perspective of an aircraft with course equals heading.

What is a CDI in aircraft navigation?

A course deviation indicator ( CDI) is an avionics instrument used in aircraft navigation to determine an aircraft's lateral position in relation to a track. If the location of the aircraft is to the left of course, the needle deflects to the right, and vice versa.

What is a CDI receiver?

CDI's were originally designed to receive a signal from a VOR, LDA or ILS receiver. These receivers outputted a signal composed of two AC voltages. A converter decoded this signal, and by determining the desired heading or radial from a resolver connected to the OBS knob, provided a control voltage to drive the needle left or right. Most of the older units, and many newer ones, contain the converter in the CDI. Generally, CDI units with an internal converter are not compatible with GPS units.

What is CDI in navigation?

A CDI can be its own standalone instrument used for VOR navigation, or it can be part of an HSI which also integrates a heading indicator. When part of an HSI, the CDI is more just the actual course deviation needle on the instrument rather than the entire instrument itself.

Why is CDI confusing?

The reason the CDI can be a little confusing is because it can either be its own standalone instrument (used for VOR navigation) or it can be a component within an HSI (Horizontal Situation Indicator).

What is HSI in music?

The HSI is an improvement on the standalone CDI instrument in that it takes into consideration your actual heading. The old CDI would just have a radial set in the OBS and show your deviation (which could have reverse sensing depending on which radial you tuned) in relation to that radial. The HSI serves as a heading indicator as well as a CDI ...

Does the heading bug control HSI?

It’s incredibly flexible because of this and I never have any reverse sensing in the cockpit. The heading bug does not control anything in the HSI per se, but is more of a “target” you can set if you are assigned a heading by ATC or if you are trying to remember your wind correction angle when tracking a VOR.

Is reverse sensing a malfunction?

It isn’t a malfunction of the instrument, just something you have to be keenly aware of particularly when flying IFR. As you can tell (or as you might know from personal experience), the potential to have reverse sensing in the cockpit can lead to some major issues.

Can you reverse sensing a CDI needle?

Because of this there is a real downside to the standalone CDI instrument and that is you can have reverse sensing.
