BRICK TYPE | SPECIFIED SIZE D X H X L (INCHES) | VERTICAL COURSE |
---|---|---|
Modular | 3 5/8 x 2 1/4 x 7 5/8 | 3 courses = 8" |
Norman | 3 5/8 x 2 1/4 x 11 5/8 | 3 courses = 8" |
Roman | 3 5/8 x 1 5/8 x 11 5/8 | 1 course = 2" |
Jumbo | 3 5/8 x 2 3/4 x 8 | 1 course = 3" |
A brick course is equivalent to a standard brick height (76mm) and the mortar (10mm) that holds the bricks above it together. Therefore, a brick course is 86mm. Variance in brick sizes
The predominant mortar joint width used in construction is 3/8". In fact, the International Building Codes reference TMS 602 Specification for Masonry Structures, which defaults to a 3/8" mortar joint so this should be the main starting point for architects and engineers, but always confirm the specified size of your selected brick.
The dimensions of brick coursing are typically expressed in terms of a linear dimension and a multiplier, such as 12x 8. In this example, the brick coursing measures 12 inches wide and 8 inches tall.
Standard brick sizes vary from country to country, with dimensions written as depth x height x length (D x H x L). Standard brick dimensions may be expressed in either imperial units, in terms of inches, or metric units, as millimeters.
A brick course is equivalent to a standard brick height (76mm) and the mortar (10mm) that holds the bricks above it together. Therefore, a brick course is 86mm.
75 mmStandard bricks With a standard mortar joint of 10 mm, a repeating unit of bricks laid in a stretcher bond will be 225 mm lengthwise and 75 mm in height.
Mortar joints are typically 3/8", but can vary from 1/4" to 1/2" — we cover this more in our brick sizes article. Bed joints are the horizontal mortar joints, or the bed of mortar that the next brick sits on. Full mortar bedding joints cover the entire top of the masonry unit and are the most common bedding type.
The most common mortar joint size is 3/8 of an inch, or . 38 inch, as specified by the International Building Codes TMS 602, on the “Specifications for Masonry Structures.” Mortar joints that measure 1/2 inch are also common.
A 'course' is a measurement referring to the dimensions of the brick AND mortar when they have been sandwiched together. One brick and the mortar together is equal to one 'course'.
A wall built with a standard modular brick will require seven bricks per square foot to complete the project. Projects using different sizes may need more or less. Follow the steps below for an accurate estimate.
4. Minimum thickness of mortar or grout between brick and reinforcement: 1/4 in. (6.4 mm), except: a. 1/4 - in.
The building code for weight-bearing brick walls calls for mortar to be no more than 3/8 inch thick.
In masonry, mortar joints are the spaces between bricks, concrete blocks, or glass blocks, that are filled with mortar or grout.
The combined thickness of one course including that of the mortar should not exceed 7.6 cm in any layer/course. The brickwork for all is always started from both the ends. In general walls are constructed as ½ brick thick, 1½ bricks thick, 2 bricks thick, 2½ brick thick and 3 brick thick which we see in our daily life.
The most popular brick size is a Modular brick measuring at 3-5/8" thick by 2-1/4" high and 7-5/8" long.
65mm highNowadays most bricks in the UK are made to a standard brick size of 215mm long, 102.5mm wide and 65mm high (215 x 102.5 x 65mm) and laid with a nominal 10mm mortar joint.
A brick course is equivalent to a standard brick height ( 76mm) and the mortar (10mm) that holds the bricks above it together. Therefore, a brick course is 86mm.
Two course brick standard size is 162mm high x 290mm long x 90mm wide. This brick is just as durable as a standard face brick but is a cheaper alternative due to the fact they make building walls much quicker.
This is because it takes less time and labour to lay and build the walls. A Standard internal brick size is 162mm high x 305mm long x 90mm wide.
There are multiple brick sizes in Australia depending on the type of brick you are using. The standard brick size is 76mm high x 230mm long x 110mm wide. This is the normal face brick. However, different style bricks such as internal fast bricks and double course bricks are not the same. Type of brick.
The most common brick is the face brick and is mostly used on external walls. This type of brick increases the aesthetics of the home and does not need to be cement rendered over the top. People choose this brick in the modern day to give their home a classic or industrial look. Common face brick size is 76mm high x 230mm long x 110mm wide.
This type of brick is not as weather proof as a face brick and is more affordable. It is easier to cut to the sizes needed when building walls and it is plastered or rendered over the top.
A standard UK brick size is 215mm long x 102.5mm wide x 65mm high according to British Standards. The length of the brick is equal to twice its width plus one 10mm mortar joint, and three times its hight plus two standard mortar joints.
Special Bricks. Special bricks are used to create different designs, shapes, features and detailing. There are a few British Standard special bricks that are widely available, these include: It is also possible to get non standard bespoke bricks from different brick suppliers.
Standard brick sizes vary from country to country, with dimensions written as depth x height x length (D x H x L). Standard brick dimensions may be expressed in either imperial units, in terms of inches, or metric units, as millimeters. Here are the specified dimensions of standard bricks in a few different countries.
When discussing brick sizing, three kinds of dimensions may be referenced:
Modular bricks are sized so that their nominal dimensions are round numbers or will add up to round numbers when bricks are grouped. Their standard and predictable sizes make it easy for them to be slotted together in construction, or in renovations, where they can be substituted for damaged or missing bricks.
Bricks can be laid multiple ways, in different arrangements, with different surfaces exposed to the exterior. In layman’s terms, we might speak of a brick being vertical, horizontal, sideways, or lying flat, but these fail to convey both the attitude and the position of the brick.
Bond patterns are used for different purposes in brickwork. For example, the bonds listed below are often found on building faces.
Bricks can be used in a variety of ways for both functional and aesthetic purposes, and projects can involve bricklaying by hand or with the help of equipment such as forklifts and telehandlers.
There are three different ways of discussing sizes when it comes to brick and it is important to understand the different sizes so there isn't any confusion - we will start by discussing the different dimensions: specified, actual, and nominal.
Architects are mostly interested in the aesthetic appearance of the brick wall, but when it comes to detailing it is important to understand the sizes of bricks. That said, most architects will select bricks based on their color and bond pattern. The size of the brick is tied to the bond pattern and manufacturer specifics.
The predominant mortar joint width used in construction is 3/8". In fact, the International Building Codes reference TMS 602 Specification for Masonry Structures, which defaults to a 3/8" mortar joint so this should be the main starting point for architects and engineers, but always confirm the specified size of your selected brick.
When calculating brick openings, you count the courses (vertical) or brick lengths (horizontal) to get the Masonry Opening (M.O.). However, to get the actual opening you have to factor in the additional mortar joint that is missing from the standard nominal dimensions.
The diagrams below represent the orientations for bricks as they are laid in walls. The red face is the face that is exposed. Different orientations are combined to create brick bonds.
Architects generally select bricks based on the type of application. Many factors go into the selection, including durability ( see Grades below ), load capacity, and appearance. The following table covers the major types of brick, their ASTM specification criteria, and the general usage applications.
Brick grades indicate the durability of a brick when it is exposed to moisture and freezing. There are three factors that help determine brick durability: compressive strength, water absorption, and the saturation coefficient.
